Adjustable hydraulic feed system. Adjustable ball bearing guides. Heat treated steel worm gear and bronze drive gear.
Features:
- For added safety, the motor and electrics follow strict guidelines and electrical requirements to be certified by CSA Group
- UL Listed Motor
- Blade drive is a sealed, steel, heat treated worm driving a bronze worm gear in an oil bath
- Mitering head swivels to cut any angle 0° - 60° while the work piece remains secured
- Ball bearing supported blade wheel
- Fully adjustable hydraulic downfeed system
- Deluxe enclosed stand with wheels and handle for easy movement
- Adjustable material stop
- 1/2" Carbon Steel Blade
Specifications:
- Motor (HP) 1/2 HP, 115V, 1Ph
- Cutting Capacity (W x D) (In.) 5 x 8
- Blade Speeds (SFPM) 85, 125, 200
- Round at 90 Degrees (In.) 5
- Round at 45 Degrees (In.) 4-1/2
- Rectangle at 90 Degrees (In.) 7-1/2 x 5
- Rectangle at 45 Degrees (In.) 4-1/2 x 5
- Square at 90 Degrees (In.) 5
- Vise Swivels (Deg.) 45
- Overall Dimensions (L x W x H) (In.) 37 x 16 x 37
- Blade Length (In.) 68-1/2
- Bed Height (In.) 23-1/2
- Blade Wheel Diameter (In.) 7-1/2
- Blade Size (In.) 1/2 x .025 x 68
- Motor Phase 1
- Weight (Lbs.) 134
- Prewired (V.) 115
