Standard Equipment
- Ram Deflection Adjustment
- Mechanical Ram Depth Control
- Massive Torsion Bar for Parallelism
- Forged Heavy Duty Cylinder and Cylinder Body
- Three Speed Ram
- Rapid Approach, Bending Cycle and Rapid Retreat
- Bottom Time Delay
- All Steel Construction
- Inching, Single Cycle and Continuous Operation
- Ram takes standard American Tang Tooling (1/2" x 5/8")
- Space between Ram Tool Clamps allows for deep box bending
- Bed has slot for standard American tang tooling
- Bed also holds tooling with capture clamps
Options Included
- CNC 2-Axis Color Graphic Control
- Controls BOTH Bend Angle and Backgauge Position. Comes with 6” LCD touchscreen. Code and Graphic programming included. Graphic allows 10 bends per program/cross-section. Controls features a tool library, Metric/inch switchable, Auto bend sequence, Auto retract of Backgauge, Spread length, Interference bend alert, Calculated bend allowance, Programmable ram dwell and much more. Control stores thousands of programs with USB Port, Ethernet and RS232 for program backup.
- Sick Model 4000 Light Curtain System
Specifications
- Working Pressure: 155 Tons
- Length of Working Table: 157.4"
- Distance Between Housings: 124"
- Throat Depth: 12.5"
- Stroke Adjustment of Ram: 2.75"
- Ram Travel: 5.9"
- Open Height: 16.3"
- Rapid Ram Travel Speed: 2.4" / Sec.
- Rapid Ram Retreat Speed: 2.0" / Sec.
- Backgauge Travel: 24"
- Pressing Speed: Dependent on Tool Load
- Hydraulic Oil Capacity: 97 Gal.
- Motor Horsepower: 15 HP
- Net Weight: 23,148 lbs.
- Length: 179"
- Width: 64"
- Height: 101"
Options
- CNC 2-Axis Color Graphic Control
- Controls BOTH Bend Angle and Backgauge Position. Comes with 6” LCD touchscreen. Code and Graphic programming included. Graphic allows 10 bends per program/cross-section. Controls features a tool library, Metric/inch switchable, Auto bend sequence, Auto retract of Backgauge, Spread length, Interference bend alert, Calculated bend allowance, Programmable ram dwell and much more. Control stores thousands of programs with USB Port, Ethernet and RS232 for program backup.
- Sick Model 4000 Light Curtain System
- Fiessler Akas II Laser Guarding
- Pilz PSENvip LED Safety Guarding
- Third Axis (Back Gauge Height)
- CNC Controlled Mechanical Auto Crown
- High Speed Servo Back Gauge:Training in Memphis, TN Showroom
- Training at customer site, less than 300 miles from Memphis
- Training at customer site, more than 300 miles from Memphis
