GMC Machinery 70-Ton 6’ CNC Press Brake – Small Hydraulic Press Brake

(No reviews yet) Write a Review
Price: $38,850.00
SKU:
HPB-7006
Roll over image to zoom in
  • ISO 9001 certified
  • Meet OSHA and CE safety standard
  • ESA (Italy) Model 625, 2 Axis CNC Controller
  • Die library, offline programming, stores thousands of programs
  • Programmable Angle/ Angle Correct
  • Germany Rexroth hydraulic system
  • Yaskawa Servo motor and Drives
  • Schneider electrical components
  • Hydraulic crowning
  • All steel construction for maximum rigidity
  • Hydraulic logic system centrally located and quiet
  • Safety type foot pedal with handle and E-stop switch
  • Safety 24V low voltage & overload protection
  • One year industrial warranty for parts
  • ESA (Italy) Model 625, 2 Axis CNC Controller
  • (2) 24” front support arms, Quick Release for easy positioning
  • Quick release segmented (American Style Tooling) punch holder
  • Full Length Gooseneck Punch HRC 50 ( Punch is rated for 10 gauge and lighter .062” radius punch) Additional Tooling may be required for thicker materials and purchaser’s specific products/parts - Ask your dealer for custom tooling quotes)
  • Full Length Vee Die with 6 assorted sizes HRC 50
  • Lntech Light Curtain System
  • Side and Back Safety Fence
  • Movable Foot Pedal with Estop meet OSHA safety standard

Maximum Pressure 70 Tons
Bending Lenght Capacity 80" (6'8")
Distance Between Uprights (housing) 63"
Ram Stroke Travel

Cylinder Travel Adjustment (max)

6"

3 1/8"

Table Width 6"
Distance Between Table and Ram

Max Stacked Tooling Height

15 1/4"

8-1/2"

Throat Depth 10"
Back Gauge Distance 24"
Back Gauge Repeatability .0039"
Y-Axis Repeatability .0039"
Approach speed, inch / second

Working speed, inch / second

Return speed, inch / second

3.14”

0.35”

2.36”

Main motor:





Servo motor for back gauge:



Servo motor for bending angle

setting

7-1/2 HP, 3 Phase 30 AMP

Prewired: 220VAC (+/- 10%)



1 HP, 3 Phase

220VAC (+/- 10%)



1/2HP, 3 Phase

220VAC (+/- 10%)

Hydraulic oil tank capacity:

Recommended Oil:

52 Gal.

Hydraulic Oil Shell #68HD

Machine weight:

Machine size, L x W x H:

Shipping Dimensions:

8,650 LBS

103" x 63" x 87”

109"x66"x98"
